1s = MD5(appkey + appkey值 + auth_ver + auth_ver值 + nonce + nonce值 + appSecret值)

1String paramsStr = "appkey" + appKey +
2        "auth_ver" + authVer +
3        "nonce" + System.currentTimeMillis() +
4        appSecret;//接口签名密钥（可配置）
5String sign = org.apache.commons.codec.digest.DigestUtils.md5Hex(paramsStr.getBytes(StandardCharsets.UTF_8));

1    // 填装实际接口请求参数
2    Map param = new HashMap();
3    param.put("param1", "value1");
4    param.put("param2", "value2");
5    param.put("param3", "value3");
6
7    // 请求参数转化为JSON字符串
8    String requestParam = new Gson().toJson(param);
9
10    // 请求参数加密
11    Cipher cipher = Cipher.getInstance("DESede/CBC/PKCS5Padding");
12    SecretKeyFactory skf = SecretKeyFactory.getInstance("DESede");
13    SecretKey secretKey = skf.generateSecret(new DESedeKeySpec(desKey.getBytes("utf-8")));
14    ByteBuffer byteBuffer = ByteBuffer.allocate(8);
15    byteBuffer.order(ByteOrder.BIG_ENDIAN);
16    byteBuffer.putLong(nonce);
17    byte[] iv = byteBuffer.array();
18    IvParameterSpec ivParameterSpec = new IvParameterSpec(iv);
19    cipher.init(Cipher.ENCRYPT_MODE, secretKey, ivParameterSpec);
20    byte[] cipherText = cipher.doFinal(requestParam.getBytes("utf-8"));
21    String msg = Base64.encodeBase64String(cipherText);
22    Map map = new HashMap();
23    map.put("createTime", nonce);
24    map.put("msg", msg);
25    // 转化为JSON字符串
26    String encryptBody = new Gson().toJson(map);

1package org.example.openapi;
2
3import cn.hutool.json.JSONUtil;
4import org.apache.commons.codec.digest.DigestUtils;
5
6import javax.crypto.Cipher;
7import javax.crypto.SecretKey;
8import javax.crypto.SecretKeyFactory;
9import javax.crypto.spec.DESedeKeySpec;
10import javax.crypto.spec.IvParameterSpec;
11import java.io.ByteArrayOutputStream;
12import java.io.InputStream;
13import java.io.OutputStreamWriter;
14import java.net.HttpURLConnection;
15import java.net.URL;
16import java.nio.ByteBuffer;
17import java.nio.ByteOrder;
18import java.nio.charset.StandardCharsets;
19import java.util.Base64;
20import java.util.HashMap;
21import java.util.Map;
22
23public class OpenApiTest {
24    public static void main(String[] args) throws Exception {
25        // 云游戏平台分配给第三方用户的接口Key
26        String appKey = "4a8311be034943cfaa6a357fdc9f0461";
27        // 接口版本号，现在有2和3两种版本的接口，具体按照接口文档上的版本号
28        String authVer = "3";
29        // 当前的时间戳
30        long nonce = System.currentTimeMillis();
31        // 接口签名秘钥
32        String appSecret = "01a258aff68e6b2f2513df7f7dc3cf18";
33        // 生成方法签名
34        String paramsStr = "appkey" + appKey +
35                "auth_ver" + authVer +
36                "nonce" + nonce +
37                appSecret;//接口签名密钥（可配置）
38        String sign = DigestUtils.md5Hex(paramsStr.getBytes(StandardCharsets.UTF_8));
39        // desKey 3DES秘钥（可配置），根据商户平台实际生成的替换此值
40        String desKey = "cba76b7b0ab1011179087092effe1b8d";
41        // 拼接公共参数到URL
42        String apiUrl = "https://platform.armvm.com/{resourcePath}?s=" + sign + "&appkey=" + appKey + "&auth_ver=" + authVer + "&nonce=" + nonce;
43
44        // 填装实际接口请求参数
45        Map<String, Object> param = new HashMap<>();
46        param.put("param1", "value1");
47        param.put("param2", "value2");
48        param.put("param3", "value3");
49
50        // 请求参数转化为JSON字符串
51        String requestParam = JSONUtil.toJsonStr(param);
52
53        // 请求参数加密
54        Cipher cipher = Cipher.getInstance("DESede/CBC/PKCS5Padding");
55        SecretKeyFactory skf = SecretKeyFactory.getInstance("DESede");
56        SecretKey secretKey = skf.generateSecret(new DESedeKeySpec(desKey.getBytes(StandardCharsets.UTF_8)));
57        ByteBuffer byteBuffer = ByteBuffer.allocate(8);
58        byteBuffer.order(ByteOrder.BIG_ENDIAN);
59        byteBuffer.putLong(nonce);
60        byte[] iv = byteBuffer.array();
61        IvParameterSpec ivParameterSpec = new IvParameterSpec(iv);
62        cipher.init(Cipher.ENCRYPT_MODE, secretKey, ivParameterSpec);
63        byte[] cipherText = cipher.doFinal(requestParam.getBytes(StandardCharsets.UTF_8));
64        String msg = Base64.getEncoder().encodeToString(cipherText);
65        Map<String, Object> map = new HashMap<>();
66        map.put("createTime", nonce);
67        map.put("msg", msg);
68        // 转化为JSON字符串
69        String encryptBody = JSONUtil.toJsonStr(map);
70
71        // 构造请求
72        URL url = new URL(apiUrl);
73        HttpURLConnection httpURLConnection = (HttpURLConnection) url.openConnection();
74        // 连接超时时间
75        httpURLConnection.setConnectTimeout(1000);
76        // 读取结果超时时间
77        httpURLConnection.setReadTimeout(1000);
78        httpURLConnection.setDoInput(true);
79        httpURLConnection.setDoOutput(true);
80        httpURLConnection.setUseCaches(false);
81        httpURLConnection.setRequestProperty("Content-type", "application/json;charset=utf-8");
82        httpURLConnection.setRequestMethod("POST");
83
84        // 得到请求的输出流对象
85        OutputStreamWriter out = new OutputStreamWriter(httpURLConnection.getOutputStream());
86        // 把数据写入请求的Body
87        out.write(encryptBody);
88        out.flush();
89        out.close();
90
91        String result;
92        try (InputStream in = 200 == httpURLConnection.getResponseCode() ? httpURLConnection.getInputStream() : httpURLConnection.getErrorStream();) {
93            byte[] buf = new byte[1024];
94            int length;
95            ByteArrayOutputStream bout = new ByteArrayOutputStream();
96            while ((length = in.read(buf, 0, buf.length)) > 0) {
97                bout.write(buf, 0, length);
98            }
99            bout.flush();
100            result = new String(bout.toByteArray(), StandardCharsets.UTF_8);
101        } finally {
102            httpURLConnection.disconnect();
103        }
104        int responseCode = httpURLConnection.getResponseCode();
105        if (responseCode == 200) {
106            System.out.println("调用成功,接口返回结果:\n" + result);
107        } else {
108            System.out.println("调用失败");
109        }
110    }
111}

1import json
2import time
3import hashlib
4import base64
5import struct
6
7import requests
8from Crypto.Cipher import DES3
9from Crypto.Util.Padding import pad
10
11
12def _pad(data):
13    padding_length = 8 - len(data) % 8
14    padding = bytes([padding_length] * padding_length)
15    return data + padding
16
17
18def encrypt(key, iv, message):
19    cipher = DES3.new(key[:24].encode('utf-8'), DES3.MODE_CBC, struct.pack('>Q', iv))
20    padded_message = pad(message.encode('utf-8'), DES3.block_size)
21    ciphertext = cipher.encrypt(padded_message)
22    return ciphertext
23
24
25def encrypt_with_base64(key, iv, message):
26    ciphertext = encrypt(key, iv, message)
27    return base64.b64encode(ciphertext).decode('utf-8')
28
29
30if __name__ == '__main__':
31    # 云游戏平台分配给第三方用户的接口Key
32    app_key = "4a8311be034943cfaa6a357fdc9f0461"
33    # 接口版本号，现在有2和3两种版本的接口，具体按照接口文档上的版本号
34    auth_ver = "3"
35    # 当前的时间戳
36    nonce = int(time.time() * 1000)
37    # 接口签名秘钥
38    app_sec = "01a258aff68e6b2f2513df7f7dc3cf18"
39    # 方法签名
40    sign = "appkey%sauth_ver%snonce%d%s" % (app_key, auth_ver, nonce, app_sec)
41    md5_sign = hashlib.md5(sign.encode('utf-8')).hexdigest()
42    # desKey 3DES秘钥（可配置），根据商户平台实际生成的替换此值
43    des_key = "cba76b7b0ab1011179087092effe1b8d"
44    # 拼接公共参数到URL
45    url = "https://platform.armvm.com/resourcePath?appkey=%s&auth_ver=%s&s=%s&nonce=%d" % (app_key, auth_ver, md5_sign, nonce)
46    data = {
47        "param1": "value1",
48        "param2": "value2",
49        "param3": "value3",
50    }
51    msg = encrypt_with_base64(des_key, nonce, json.dumps(data))
52    post_data = {
53        "msg": msg,
54        "createTime": nonce
55    }
56    print('url = ', url)
57    print('data = ', post_data)
58    res = requests.post(url, json.dumps(post_data), headers={
59        'Content-Type': 'application/json'
60    })
61    print(res.text)

1package main
2
3import (
4	"bytes"
5	"crypto/md5"
6	"encoding/base64"
7	"encoding/hex"
8	"encoding/json"
9	"fmt"
10	"github.com/forgoer/openssl"
11	"net/http"
12	"time"
13)
14
15func encryptWithBase64(key string, iv int64, message string) (string, error) {
16	ivBytes := make([]byte, 8)
17	for i := 0; i < 8; i++ {
18		ivBytes[7-i] = byte(iv >> (8 * i))
19	}
20	ciphertext, err := openssl.Des3CBCEncrypt([]byte(message), []byte(key)[:24], ivBytes, openssl.PKCS7_PADDING)
21	if err != nil {
22		return "", err
23	}
24	return base64.StdEncoding.EncodeToString(ciphertext), nil
25}
26
27func main() {
28	appKey := "4a8311be034943cfaa6a357fdc9f0461"
29	authVer := "3"
30	nonce := time.Now().UnixNano() / int64(time.Millisecond)
31	appSec := "01a258aff68e6b2f2513df7f7dc3cf18"
32
33	sign := fmt.Sprintf("appkey%sauth_ver%snonce%d%s", appKey, authVer, nonce, appSec)
34	md5Sum := md5.Sum([]byte(sign))
35	md5Sign := hex.EncodeToString(md5Sum[:])
36
37	desKey := "cba76b7b0ab1011179087092effe1b8d"
38
39	url := fmt.Sprintf("https://platform.armvm.com/resourcePath?appkey=%s&auth_ver=%s&s=%s&nonce=%d", appKey, authVer, md5Sign, nonce)
40
41	data := map[string]string{
42		"param1": "value1",
43		"param2": "value2",
44		"param3": "value3",
45	}
46
47	jsonData, err := json.Marshal(data)
48	if err != nil {
49		fmt.Println("Error marshalling JSON:", err)
50		return
51	}
52
53	msg, err := encryptWithBase64(desKey, nonce, string(jsonData))
54	if err != nil {
55		fmt.Println("Encryption error:", err)
56		return
57	}
58
59	postData := map[string]interface{}{
60		"msg":        msg,
61		"createTime": nonce,
62	}
63
64	postDataJson, err := json.Marshal(postData)
65	if err != nil {
66		fmt.Println("Error marshalling post data:", err)
67		return
68	}
69
70	fmt.Println("url = ", url)
71	fmt.Println("data = ", string(postDataJson))
72
73	req, err := http.NewRequest("POST", url, bytes.NewBuffer(postDataJson))
74	if err != nil {
75		fmt.Println("Error creating request:", err)
76		return
77	}
78	req.Header.Set("Content-Type", "application/json")
79
80	client := &http.Client{}
81	resp, err := client.Do(req)
82	if err != nil {
83		fmt.Println("Error making request:", err)
84		return
85	}
86	defer resp.Body.Close()
87
88	var responseBytes bytes.Buffer
89	_, err = responseBytes.ReadFrom(resp.Body)
90	if err != nil {
91		fmt.Println("Error reading response:", err)
92		return
93	}
94
95	fmt.Println(responseBytes.String())
96}

1{
2    "code": 0,
3    "msg": "OK",
4    "data": {
5        "successList": [
6            {
7                "instanceCode": "VM192168169027",
8                "serverToken": "50b13132bb394901f151bc45"
9            }
10        ],
11        "errorList": [
12            {
13                "instanceCode": "VM192168169028",
14                "errorMsg": "实例不存在"
15            },
16            {
17                "instanceCode": "VM192168169029",
18                "errorMsg": "实例不存在"
19            }
20        ]
21    },
22    "ts": "1658455442690"
23}

1{
2  "code": 11101118,
3  "msg": "商户类型错误,只允许云手机客户使用",
4  "ts": "1658455442690"
5}

1{
2    "code": 0,
3    "data": {
4        "instanceCode": "VM192168169028",
5        "serverToken": "c5039adcda344cebb748e94644fbc68f5"
6    },
7    "msg": "OK",
8    "ts": "1694584934947"
9}

1{
2    "code": 11103270,
3    "msg": "实例暂未被使用，不能对该实例申请授权",
4    "ts": 1601192809490
5}

1{
2    "code": 11103271,
3    "msg": "当前实例授权连接个数已达上限",
4    "ts": 1601192809490
5}

1{
2  "code": 0,
3  "data": {},
4  "msg": "OK",
5  "ts": "1658455442690"
6}

1{
2  "code": 11102027,
3  "msg": "serverToken无效",
4  "ts": "1658455442690"
5}

1{
2  "data": {
3    "failList": []
4  },
5  "code": 0,
6  "msg": "OK",
7  "ts": "1702454509182"
8}

1{
2  "code": 11102027,
3  "msg": "serverToken无效",
4  "ts": "1702458796121"
5}

1{
2  "data": {
3    "failList": []
4  },
5  "code": 0,
6  "msg": "OK",
7  "ts": "1702454509182"
8}

1{
2  "code": 11102027,
3  "msg": "serverToken无效",
4  "ts": "1702458796121"
5}

1{
2  "data": [
3    {
4      "instanceCode": "VM011101100190",
5      "serverToken": "49b1f2943e04468383b10e4acafaad2d5",
6      "uuid": "72f4d5bc0036",
7      "businessType": "cloud_phone",
8      "bindTime": 1734578634443,
9      "expireTime": 1735587244443,
10      "controlStatus": "online",
11      "grantControl": "CONTROL",
12      "instanceControlTime": null
13    }
14  ],
15  "code": 0,
16  "msg": "OK",
17  "ts": "1734578646712"
18}

1{
2  "code": 11103062,
3  "msg": "实例不存在",
4  "ts": "1734578806958"
5}

1{
2  "data": {},
3  "code": 0,
4  "msg": "OK",
5  "ts": "1734578060146"
6}

1{
2  "code": 11103062,
3  "msg": "实例不存在",
4  "ts": "1734578078843"
5}
6
7{
8  "code": 11103397,
9  "msg": "实例存在云游戏或OEM的绑定信息，暂不支持调用此接口解绑",
10  "ts": "1734578136525"
11}

1{
2  "code": 0,
3  "data": {
4    "successList": ["50b13132bb394901f151bc45"],
5    "failList": [
6      {
7        "serverToken": "50b13132bb394901f151bc46",
8        "msg": "serverToken无效"
9      }
10    ]
11  },
12  "msg": "OK",
13  "ts": "1658455442690"
14}

1{
2  "code": 0,
3  "data": {
4    "total": 20,
5    "totalPage": 2,
6    "page": 1,
7    "rows": 10,
8    "pageData": [
9      {
10        "instanceCode": "VM192168232001",
11        "instanceIp": "192.168.232.1",
12        "deviceIp": "192.168.1.100",
13        "deviceCode": "GZNX-IDC_DM011010099026",
14        "instanceType": "business",
15        "serverType": "G4",
16        "instanceGrade": "1",
17        "romVersion": "android12.0",
18        "merchantPoolNo": 1,
19        "idcCode": "GZNX-IDC-02",
20        "idcName": "南翔机房-可用区1",
21        "availableStatus": "available",
22        "usableStatus": "usable",
23        "maintainStatus": 0,
24        "recycleStatus": "normal",
25        "taskStatus": "none",
26        "instanceStatus": 1,
27        "deviceStatus": 1,
28        "malfunctionStatus": 0,
29        "networkStatus": 0,
30        "bindStatus": "bindable",
31        "controlStatus": "online",
32        "imageVersionId": 10001,
33        "imageVersionName": "3588_aosp10_v2.25.1(2025-03-13)",
34        "snapshotMountStatus": "mounted",
35        "snapshotId": 5001,
36        "memoryLimit": 1024,
37        "upSpeed": 100.0,
38        "downSpeed": 100.0,
39        "intranetUpSpeed": 10.0,
40        "intranetDownSpeed": 10.0,
41        "allocateTime": 1733297481137,
42        "recycleTime": 1733297481137
43      }
44    ]
45  },
46  "msg": "success",
47  "ts": 1733297481137
48}

1{
2    "code": 0,
3    "msg": "success",
4    "ts": 1658455442690,
5    "data": {
6        "totalData": {
7            "totalInstanceCount": 10,
8            "idcList": [
9                {
10                    "idcName": "广州机房",
11                    "idcCode": "GZ-IDC-01",
12                    "instanceCount": 10
13                }
14            ]
15        },
16        "boundData": {
17            "totalInstanceCount": 5,
18            "idcList": [
19                {
20                    "idcName": "广州机房",
21                    "idcCode": "GZ-IDC-01",
22                    "instanceCount": 5
23                }
24            ]
25        },
26        "availableData": {
27            "totalInstanceCount": 5,
28            "idcList": [
29                {
30                    "idcName": "广州机房",
31                    "idcCode": "GZ-IDC-01",
32                    "instanceCount": 5
33                }
34            ]
35        }
36    }
37}

1{
2    "code": 0,
3    "msg": "OK",
4    "data": [
5        {
6            "appInstallList": [
7                {
8                    "appName": "demo",
9                    "packageName": "com.demo",
10                    "versionName": "1.0.1",
11                    "appId": 1001,
12                    "appIconUrl": "https://demo.com/xxx.jpg"
13                }
14            ],
15            "storageSum": 100.0,
16            "storageFree": 82.8,
17            "padCode": "VM192168001001"
18        }
19    ],
20    "ts": "1658455442690"
21}

1{
2    "code": 11100050,
3    "msg": "系统异常，请联系客服人员"
4}

1{
2  "code": 0,
3  "data": {
4    "totalAvailableCount": 128,
5    "idcInfos": [
6      {
7        "idcName": "北京机房",
8        "idcCode": "BJ-1001",
9        "availableCount": 20
10      },
11      {
12        "idcName": "广州机房",
13        "idcCode": "GZ-10012",
14        "availableCount": 108
15      }
16    ],
17    "msg": "",
18    "ts": 1601021167163
19  }
20}

1{
2  "code": 0,
3  "data": {
4    "totalEnableBindCount": 2000,
5    "idcInfos": [
6      {
7        "idcName": "北京机房",
8        "idcCode": "BJ-1001",
9        "enableBindCount": 1001
10      },
11      {
12        "idcName": "广州机房",
13        "idcCode": "GZ-10012",
14        "enableBindCount": 999
15      }
16    ],
17    "msg": "",
18    "ts": 1601021167163
19  }
20}

1{
2  "code": 0,
3  "data": [
4    {
5      "taskId": 1001,
6      "padCode": "VM192168043080"
7    },
8    {
9      "taskId": 1002,
10      "padCode": "VM192168043091"
11    }
12  ],
13  "msg": "",
14  "ts": 1668572148662
15}

1{
2    "code":11103062,
3    "msg":"实例不存在",
4    "ts":"1668586771490"
5}

1{
2  "code": 0,
3  "data": [
4    {
5      "taskId": 1001,
6      "padCode": "VM192168043080",
7      "taskStatus": 7,
8      "url":"https://platform.armvm.com/files/screenshot/6a8030673f534b9c948c58b51c615553.png"
9    },
10    {
11      "taskId": 1002,
12      "padCode": "VM192168043091",
13      "taskStatus": 7,
14      "url":"https://platform.armvm.com/files/screenshot/6a8030673f534b9c948c58b51c615555.png"
15    }
16  ],
17  "msg": "",
18  "ts": 1668572148662
19}

1{
2  "code":11109015,
3  "msg":"操作失败，请输入正确的任务ID",
4  "ts":"1668584368093"
5}

1{
2    "code": 0,
3    "msg": "OK",
4    "data": [
5        {
6            "taskId": "89695",
7        },
8    ],
9    "ts": "1658455442690"
10}

1{
2    "code": 11100064,
3    "msg": "查询开始时间不能早于前60天",
4    "ts": 1601192809490
5}

1{
2    "code": 11100065,
3    "msg": "查询结束时间只能到60分钟以前",
4    "ts": 1601192809490
5}

1{
2    "code": 11109021,
3    "msg": "当前已有%s个查询任务正在执行，超过任务个数限制，请稍后再试",
4    "ts": 1601192809490
5}

1{
2    "code": 11100050,
3    "msg": "系统异常，请联系客服人员",
4    "ts": 1601192809490
5}

1{
2    "code": 0,
3    "msg": "OK",
4    "data": {
5        "msg": "",
6        "billingValue": 100.0,
7        "taskStatus": "SUCCESS",
8        "billingType": "FLOW",
9        "taskId": "89695",
10        "taskDesc": "2023年2月份流量计费汇总",
11        "bandwidthList": [
12            {
13                "recordTime": 1676020200000,
14                "receive": 50.0,
15                "send": 50.0
16            }
17        ]
18    },
19    "ts": "1658455442690"
20}

1{
2    "code": 11108002,
3    "msg": "请输入正确的任务ID",
4    "ts": 1601192809490
5}

1{
2    "code": 11100050,
3    "msg": "系统异常，请联系客服人员",
4    "ts": 1601192809490
5}

1{
2  "code": 0,
3  "data": [
4    {
5      "taskId": 1001,
6      "instanceCode": "VM192168043080"
7    },
8    {
9      "taskId": 1002,
10      "instanceCode": "VM192168043091"
11    }
12  ],
13  "msg": "",
14  "ts": 1668572148662
15}

1{
2    "code":11103062,
3    "msg":"实例不存在",
4    "ts":1668586771490
5}

1{
2    "code":11103082,
3    "msg":"自定义路径禁止包含[.]或空格",
4    "ts":1668586771490
5}

1{
2  "code": 0,
3  "data": [
4    {
5      "taskId": 1001,
6      "padCode": "VM192168043080"
7    },
8    {
9      "taskId": 1002,
10      "padCode": "VM192168043091"
11    }
12  ],
13  "msg": "",
14  "ts": 1668572148662
15}

1{
2    "code":11103062,
3    "msg":"实例不存在",
4    "ts":"1668586771490"
5}

1{
2    "code": 0,
3    "data":[
4        {
5            "taskId": 100000,
6            "instanceCode": "VM192168001001",
7          	"snapshotId": 7290017192180314133,
8          	"snapshotName": "VM192168001001_0925"
9        }
10    ],
11    "msg": "",
12    "ts": 1601188620078
13}

1{
2  "code": 11103062,
3  "msg": "实例不存在",
4  "ts": 1601021167163
5}

1{
2    "code": 0,
3    "data":[
4        {
5            "taskId": 100000,
6            "instanceCode": "VM192168001001"
7        }
8    ],
9    "msg": "",
10    "ts": 1601188620078
11}

1{
2  "code": 11108050,
3  "msg": "实例快照未完成创建",
4  "ts": 1601021167163
5}

1{
2    "code": 0,
3    "data": {
4        "total": 1,
5        "totalPage": 1,
6        "page": 1,
7        "rows": 10,
8        "pageData": [
9            {
10                "snapshotId": 7290017192180314133,
11                "snapshotName": "VM192168001001_0925",
12                "snapshotStatus": "create_success",
13                "snapshotSize": 2048
14            }
15        ]
16    },
17    "msg": "",
18    "ts": 1601021167163
19}
